7-inch SIP Video Intercom JSL-I92: Durable Outdoor Access Control Solution

Short Description:

The JSL-I92 7-inch SIP Video Intercom is a durable, weatherproof, and vandal-resistant communication terminal designed for outdoor environments. Featuring HD video and clear two-way audio, it ensures reliable communication and secure access management. With IP66 waterproof and IK07 impact-resistant ratings, it withstands harsh weather and physical impact. Integrated security, SIP protocol compatibility, and broadcasting functions make it ideal for residential, commercial, and industrial access control systems, providing both durability and intelligent connectivity for modern smart entry solutions.

Send email to us

Product Detail

Product Tags

Product Description

• Sleek and sturdy aluminum alloy panel in modern silver-gray, offering both aesthetics and durability

• Large 7-inch high-resolution capacitive touch screen (1024×600), easy to use and highly responsive

• Engineered for outdoor installation with high resistance to impact and weather (IP66 & IK07 rated)

• Optimized wide-angle lens for full entryway coverage, including low-height visibility

• Dual 2MP HD cameras with infrared night vision for round-the-clock video surveillance

• Multiple access modes: RFID cards, NFC, PIN code, mobile control, and indoor button

• Supports up to 10,000 face and card credentials, and stores 200,000+ door access logs

• Integrated relay interface supports electronic/magnetic locks with configurable unlock delay (1–100s)

• Non-volatile memory retains user database and configurations during power loss

• Up to 10 outdoor stations can be connected in a single building system

• PoE-enabled for simplified wiring, also supports DC12V power input

• ONVIF support for connection to NVRs or third-party IP surveillance systems

• Designed with accessibility features for inclusive use, including hearing aid loop output and customizable time plans

• Ideal for residential buildings, office entrances, gated communities, and commercial properties

Product Feature

•Built-in HD camera with night-vision feature

•Fitted with a tamper switch that detects unauthorized opening of the device itself

•HD voice speech quality with built-in 3W speaker and Acoustic Echo Canceller

•Built-in 3 short-in detect port and 2 short-out control port

•High accuracy face recognition algorithm, anti-deception algorithm for pictures, videos, mask attacks, face recognition accuracy is more than 99%

Specification

Panel Material	Aluminum
Color	Silver Gray
Display element	1/2.8" color CMOS
Lens	140 degree wide-angle
Light	White Light
Screen	7-inch LCD
Button Type	Mechanical Pushbutton
Capacity of Cards	≤100,00 pcs
Speaker	8Ω, 1.5W/2.0W
Microphone	-56dB
Power support	DC 12V/2A or PoE
Door Button	Support
Standby Power Consumption	<30mA
Max Power Consumption	<300mA
Working Temperature	-20°C ~ +60°C
Storage Temperature	-20°C ~ +70°C
Working Humidity	10~90% RH
Interface	Power In; Door release button;RS485; RJ45; Relay out
Installation	Wall-mounted or flush-mounted
Dimension (mm)	115.630033.2
Working Voltage	DC12V±10%/PoE
Working Current	≤500mA
IC-card	Support
Infrared diode	Installed
Video- out	1 Vp-p 75 ohm
