JSL-A8 Smart Home Panel — 8-Inch Linux Touch Screen With SIP Communication
JSL-A8 Smart Home Panel — 8-Inch Linux Touch Screen With SIP Communication
• 8-inch capacitive touch screen (800×1280 resolution)
• Linux operating system for reliable, stable performance
• Two-way SIP audio & video intercom communication
• Wi-Fi 2.4GHz & PoE for flexible installation
• RS485, relay output, bell input, 8 configurable I/O ports
• Compatible with European wall box; supports wall or desktop mounting
• Sleek plastic front panel with modern minimalist design
• Operating temperature: -10°C to +55°C
| Front Panel | Plastic |
| RAM / ROM | 128MB / 128MB |
| Display | 8 Inch TFT LCD 800 x 1280 resolurion |
| Screen | 8 Inch capacitive touch screen |
| Microphone | -42dB |
| Speaker | 8Ω / 1W |
|
Viewing Angle |
85° Left, 85° Right,85° Upper, 85° Lower |
|
Touch Screen |
Projected Capacitive |
|
Protocols Support |
IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP |
|
Video |
H.264 |
|
Audio |
SIP V1, SIP V2 |
|
Broadband Audio Codec |
G.722 |
|
Audio Codec |
G.711a, G.711μ, G.729 |
|
DTMF |
Out-of-Band DTMF (RFC2833), SIP Info |
|
Working Humidity |
10~93% |
|
Working Temperature |
-10°C ~ +55°C |
|
Storage Temperature |
-20°C ~ +70°C |
|
Installation |
Wall-mounted & Desktop |
|
Dimension |
120.9x201.2x13.8mm |
