China JSL-C35SS 5MP Motorized IR Turret Camera Factory and Manufacturer

JSL-C35SS 5MP Motorized IR Turret Camera

Short Description:

The JSL-C35SS delivers professional-grade 5MP clarity with a motorized 2.7–13.5mm lens, enabling flexible zoom and precise coverage for both wide-area monitoring and detailed capture. Powered by 120dB WDR, Smart IR, and advanced AI analytics, it ensures accurate human/vehicle detection in complex lighting conditions. Its IP66 weatherproof build, long-range IR illumination, and ONVIF compatibility make it ideal for residential, commercial, and industrial security applications.

Send email to us

Product Detail

Product Tags

Product Fetures

• 5MP (2880×1620) Ultra HD Output
• Motorized 2.7–13.5mm Lens for remote zoom control
• 120dB True WDR for strong backlight environments
• Smart IR (30m) with 2 high-power IR LEDs
• AI Analytics: human/vehicle classification, tripwire, perimeter, video/audio abnormal
• Face Capture: detects up to 8 faces / captures up to 4 simultaneously
• S+265 / H.265 / H.264 / MJPEG
• Built-in Mic + Audio I/O + Alarm I/O
• Supports microSD up to 512GB
• IP66, -40°C to +65°C, Surge & ESD Protection
• ONVIF S/T/G/M Compatible

Specification

Sensor	1/2.7" CMOS
Resolution	5MP (2880×1620 @30fps)
Illumination	Color: 0.002 Lux @F1.6; B/W: 0 Lux with IR
Shutter Time	1s ~ 1/100000s
Smart IR	Yes
Day & Night	IR-cut filter (ICR) auto switch
WDR	120dB
S/N Ratio	>39dB
Lens	Motorized 2.7–13.5mm (F1.6, Φ14)
Field of View	H: 98.3°–32.2°; V: 54.9°–18.2°; D: 125.6°–37°
DORI Distance	Detect: 56–240m; Observe: 22–95m; Recognize: 11–48m; Identify: 5.6–24m
IR LEDs	2 pcs
IR Distance	Up to 30m
Video	S+265 / H.265 / H.264B/M/H / MJPEG
Audio	G.711A/U, ADPCM_D, AAC-LC
Bit Rate	32k ~ 16Mbps
Smart Functions	AGC, BLC, HLC, 3D DNR, ROI, Defog, Corridor Mode
Video Analytics	Human/Vehicle Classification, Tripwire, Perimeter
Protocols	RTSP, RTMP, HTTP/HTTPS, TCP/UDP, IPv4/IPv6, ONVIF S/T/G/M
Local Storage	microSD Card up to 512GB
Power Supply	DC12V±25%, Max 7.5W; PoE IEEE 802.3af
Power Consumption	Max 8.5W
Working Temperature	-40℃ ~ 65℃
Storage Temperature	-40℃ ~ 65℃
Working Humidity	10~95% RH
IP Level	IP66
Dimension (mm)	132 × 132 × 108 mm
Weight	0.9 kg
