JSL-C382V 8MP Fixed Polar Day Panoramic Camera

Short Description:

The JSL-C382V is designed for ultra-wide panoramic surveillance, delivering true 8MP clarity through dual 1/2.7″ sensors. Its 180° horizontal view captures complete scenes without blind spots, supported by advanced WDR and F1.0 aperture for exceptional low-light performance. With built-in white light, AI analytics, and comprehensive alarm linkage, it is ideal for open areas such as plazas, parking lots, shops, and entrances requiring maximum coverage. PoE and multiple integrations ensure easy deployment in professional security environments.

Send email to us

Product Detail

Product Tags

Product Fetures

• Dual-Sensor 8MP Ultra-Wide Panoramic Imaging with 180° horizontal coverage
• F1.0 Super Aperture for extreme low-light performance and vivid color at night
• AI Video Analytics including human/vehicle classification, tripwire, perimeter, and abnormal detection
• Built-in White Light LEDs (15m) for full-color monitoring
• Smart Alarms & Linkage: email, sound trigger, recording, capture, warn light
• Supports microSD up to 512GB for edge storage
• ONVIF S/T/G/M Compatible for easy integration
• Industrial-Grade Reliability: -40°C to +65°C, IP67, surge & ESD protection

Specification

Sensor	Dual 1/2.7" CMOS
Resolution	8MP (4640 × 1728 @25fps)
Illumination	Color: 0.0001 Lux (F1.0); B/W: 0 Lux with IR
Shutter Time	1s ~ 1/100000s
Day & Night	Fixed IR-cut
Smart IR	Yes
WDR	120dB
S/N Ratio	>46dB
Angle	0~360°(P); 0~90°(T); 0~360°(R)
Lens	2.8mm Fixed (M12, F1.0)
Field of View	180°(H) ±10° / 65°(V) ±5°
DORI Distance	Detect 56m / Observe 22m / Recognize 11m / Identify 5.6m
White LEDs	3 pcs
White Distance	Up to 15m
Video	S+265 / H.265 / H.264 / Motion JPEG
Audio	Built-in Mic & Speaker; G.711A/U, ADPCM_D, AAC-LC
Bit Rate	32k ~ 16Mbps
Smart Functions	3D DNR, BLC, HLC, Defog, ROI, Privacy Mask
AI Analytics	Human/Vehicle, Tripwire, Perimeter, Video/Audio Abnormal
Alarm	Motion detect, mask alarm, input/output linkage
Protocols	RTSP, RTMP, HTTP/HTTPS, TCP/UDP, DHCP, DNS, NTP, IPv4/IPv6, FTP/SFTP, QoS, 802.1X
Storage	microSD up to 512GB
ONVIF	Profile S / T / G / M
Power Supply	DC12V±25% Max. 9W / PoE (802.3at)
Power Consumption	Max. 9.5W
Working Temperature	-40°C ~ 65°C
Storage Temperature	-40°C ~ 65°C
Protection	IP67, Surge 4000V, ESD 6000V
Dimensions(mm)	294 × 116 × 90 mm
Weight	1.1kg
