JSL-FD03UT-W AI Fall Monitoring Terminal with 60GHz Radar for Elderly Care
JSL-FD03UT-W AI Fall Monitoring Terminal with 60GHz Radar for Elderly Care
• 60GHz radar sensing technology enables accurate non-contact fall and activity monitoring.
• Supports fall detection, posture recognition, presence sensing, and behavior analysis.
• Provides breathing and heart rate monitoring for continuous elderly health management.
• AI algorithms deliver fast alerts with response time as low as 3 seconds.
• Supports multi-target detection with coverage up to 24㎡.
• Adjustable detection angles provide flexible installation for different environments.
• Protects user privacy with contactless monitoring without cameras or wearable devices.
• Supports Wi-Fi connectivity and optional 4G version for remote healthcare applications.
• Suitable for smart wards, nursing homes, home care, and elderly-friendly renovation projects.
• Compact design supports ceiling and wall installation for flexible deployment.
| Product Model | JSL-FD03UT-W |
| Available Versions | FD03UT-W (Wi-Fi Version) / FD03UT-4G (4G Version) |
| Product Name | Fall Monitoring Terminal |
| Detection Technology | 60GHz Millimeter Wave Radar |
| Radar Frequency | 60GHz-64GHz |
| Detection Range | 4m × 6m (24㎡) |
| Detection Angle | Vertical 120° / Horizontal 140° Adjustable |
| Detection Functions | Fall Detection, Posture Monitoring, Presence Detection, Behavior Analysis |
| Health Monitoring | Breathing Rate Monitoring, Heart Rate Monitoring, Sleep Management |
| Response Time | About 3 Seconds |
| Multi-Target Detection | Supports 3+ Target Detection |
| Network Connection | Wi-Fi / Optional 4G |
| Installation Method | Ceiling Mount (2.0-3.0m) / Wall Mount (1.5-1.6m) |
| Power Supply | USB Type-C, DC 5V/2A |
| Product Dimension | Ø86 × 26mm |
| Working Humidity | 20%-95% RH (Non-condensing) |
| Storage Temperature | -40℃ to +80℃ |
| Privacy Protection | Camera-Free Non-Contact Monitoring |
