JSL-GK-IPC3044 Wireless & Wire Dome Camera
JSL-GK-IPC3044 Wireless & Wire Dome Camera
• 4 MP progressive scan CMOS sensor for stable image acquisition
• Pan and tilt mechanism enables wide-area scene coverage
• Support for both wireless and wired network connections
• Built-in microphone and speaker for two-way audio communication
• Support for motion and sound detection
• Humanoid detection for intelligent event filtering
• Area-based alarm configuration supported
• Integrated siren for active deterrence
• Support for local microSD card storage
• Support for cloud storage via Tuya platform
• Privacy mode available for data protection
| Material | Plastic |
| CPU | AK3918AV100P |
| sensor | SC4336 |
| Image Sensor | 4 Megapixel progressive CMOS |
| Pixels | 2568(H) x 1448(V) |
| Focal Length | 4.0mm |
| Aperture | F2.0 |
| Angle of View | 92(D),77(H),44(V) |
| Pan/Tilt Angle | Horizontal:350° & Vertical: 5+90° |
| IR Distance | Up to 10m |
| Audio input | Built in Mic |
| Audio output | Built in Speaker |
| IR On/off control | Smart Mode/Infared Mode/Color Light Mode |
| Noise Reduction | 2D/3D NR |
| Compression | Main Stream: H.265 Sub Stream: H.264 |
| Resolution | Main stream:2560*1440; Sub stream: 640*360 |
| Frame Rate | 20fps |
| Two-way Talk | Support |
| Motion Detection | Support |
| Sound Detection | Support |
| Humanoid Detection | Support |
| Area Alarm | Support |
| Siren | Support |
| Reset | Reset button |
| SD slot | Micro SD Slot (up to 256GB) |
| Tuya cloud storage | Support |
| Privacy mode | Support |
| Network | Wi-Fi IEEE 802.11 a/b/g/n/ac/ax 2.4 GHz + 5 GHz + BLE + Wire network RJ45 10/100Mbps |
| Power Supply | DC 12V/1A |
| Working Temperature | -40°C～60°C |
| Humidity | ≤85% RH |
| IP Level | IP65 |
| Installation | Indoor & Outdoor |
