China JSL-H332N 3MP Fixed Color Maker Wi-Fi PT Camera Factory and Manufacturer

JSL-H332N 3MP Fixed Color Maker Wi-Fi PT Camera

Short Description:

The JSL-H332N is a 3MP Wi-Fi PT camera offering full-color imaging with smart IR and auto-tracking capabilities. It features a 4mm fixed lens, wide 51° field of view, and smooth pan & tilt control for flexible monitoring. Night vision is supported with IR up to 15m and white light up to 10m, ensuring clear footage in low-light conditions. Perfect for home or small business security, it supports H.265 compression and local storage up to 256GB.

Send email to us

Product Detail

Product Tags

Product Fetures

• 3MP resolution (2304×1296 @20fps) for crisp, full-color video
• Fixed 4mm lens with 51° horizontal field of view
• Pan & Tilt: 0–350° pan, -25–90° tilt, with 45°/s pan speed and 30°/s tilt speed
• Auto-tracking with smart alarm functionality
• Night vision: IR up to 15m, white light up to 10m
• DORI Distance: Detect 59.3m / Observe 23.5m / Recognize 11.9m / Identify 5.9m
• Supports H.265 / H.264 video compression for efficient storage
• Local storage via microSD card up to 256GB
• Wi-Fi IEEE 802.11b/g/n, up to 30m (depending on environment)
• PoE not required; powered via DC5V USB Type-C
• Compact, weather-resistant housing

Specification

Sensor	1/3" CMOS
Resolution	3MP (2304×1296 @20fps)
Illumination	Color: 0.02 Lux @ (F2.0, AGC ON); B/W: 0 Lux with IR
Shutter Time	1s ~ 1/100000s
Day & Night	IR-cut Filter with Auto Switch (ICR)
WDR	DWDR
S/N Ratio	>38dB
Lens	4mm Fixed Lens (M12, F2.0)
Field of View	51°(H) / 26.3°(V) / 60.3°(D)
DORI Distance	Detect 59.3m / Observe 23.5m / Recognize 11.9m / Identify 5.9m
Pan & Tilt	Pan 0–350° @45°/s; Tilt -25–90° @30°/s; 255 presets
IR LEDs	4 pcs
IR Distance	Up to 15m，Night Vision
IR Wavelength	850nm
White LED	1 pc, Distance: 10m
Video	S+265 / H.265 / H.264B / H.264M / H.264H
Video Bit Rate	32k ~ 4Mbps
Audio	Built-in Mic & Speaker (G.711A/U, 8/16kHz)
Smart Functions	BLC, HLC, AGC, 3D DNR, ROI, Defog
Video Analytics	Smart Alarm, Auto-Tracking
Wi-Fi	IEEE 802.11b/g/n, 2.4GHz, Range up to 30m, WPA-PSK/WPA2-PSK
Protocols	RTSP, HTTP, TCP, UDP, ICMP, DHCP, DNS, NTP, IPv4, SSH, Unicast, FTP
ONVIF	Profile S / T
Local Storage	Optional microSD card, up to 256GB
Power Supply	DC5V ±5% USB Type-C
Power Consumption	Max. 5W
Working Temperature	-10℃ ~ 45℃
Storage Temperature	-10℃ ~ 45℃
Working Humidity	10~95% RH
Protection	Surge 500V; ESD 6000V
Dimension (mm)	80 × 80 × 113 mm
Weight	0.36 kg
