JSL-H342A 4MP Fixed Color Maker Wi-Fi PT Camera
JSL-H342A 4MP Fixed Color Maker Wi-Fi PT Camera
• 4MP QHD Resolution for sharper and more detailed video output
• Pan-Tilt Function with 350° pan & 90° tilt for wide-area monitoring
• Color Maker Dual-Light Night Vision with IR + white light illumination
• Auto-Tracking automatically follows moving objects
• Smart Alarm Detection including motion alerts and linkage actions
• Wi-Fi Connectivity (2.4GHz) for easy installation
• Two-Way Audio with built-in microphone and speaker
• Supports microSD card up to 512GB for local video storage
• ONVIF Profile S/T compatibility for system integration
• Low Power Consumption (Max. 7W) and compact housing
| Sensor | 1/2.8" CMOS |
| Resolution | 4MP (2560×1440 @20fps) |
| Illumination | Color: 0.02 Lux @ (F2.0, AGC ON); B/W: 0 Lux with IR |
| Shutter Time | 1s ~ 1/100000s |
| Day & Night | IR-cut Filter with Auto Switch (ICR) |
| WDR | DWDR |
| S/N Ratio | >38dB |
| Lens | 4mm Fixed Lens (M12, F2.0) |
| Field of View | 78.9°(H) / 41°(V) / 92.9°(D) |
| DORI Distance | Detect 80m / Observe 31.75m / Recognize 16m / Identify 8m |
| Pan & Tilt | 0–350° (Pan) / -90–90° (Tilt); Presets: 255 |
| IR LEDs | 4 pcs |
| IR Distance | Up to 15m |
| IR Wavelength | 850nm |
| White LEDs | 1 pcs |
| White Distance | Up to 8m |
| Video | S+265 / H.265 / H.264B/M/H |
| Video Bit Rate | 32k ~ 4Mbps |
| Audio | Built-in Microphone & Speaker (G.711A/U, 8kHz/16kHz) |
| Smart Functions | BLC, HLC, AGC, 3D DNR, Defog, Privacy Mask |
| Video Analytics | Smart Alarm, Auto-Tracking |
| Protocols | RTSP, TCP, UDP, ICMP, DHCP, DNS, NTP, IPv4, SSH, Unicast |
| ONVIF | Profile S / T |
| Wi-Fi | IEEE802.11b/g/n, 2.4GHz, up to 30m |
| Local Storage | microSD/microSDHC/microSDXC, up to 512GB |
| Power Supply | DC5V ±5% |
| Power Consumption | Max. 7W |
| Working Temperature | -10℃ ~ 45℃ |
| Storage Temperature | -10℃ ~ 45℃ |
| Working Humidity | 10~95% RH |
| Dimension (mm) | 74 × 74 × 118 mm |
| Weight | 0.38 kg |
