JSL-H55 SIP Video Door Station
JSL-H55 SIP Video Door Station
• 5-inch HD IPS display with 720 × 1280 resolution
• Touchscreen operation combined with mechanical buttons
• Built-in dual-lens 2MP HD camera with wide dynamic range
• High-accuracy face recognition with 99.7% recognition rate
• Fast face recognition speed within 1 second
• Supports face, IC card, password, QR code, and mobile app unlocking
• Supports household password, public password, and room password
• Default face capacity of 2,000, expandable up to 20,000 users
• Default card capacity of 2,000, expandable up to 20,000 cards
• Linux operating system for long-term stability and security
• Supports SIP-based video intercom communication
• Video decoding supports H.264, H.265, 720P, and 1080P
• Automatic and manual network configuration supported
• IP65 waterproof design suitable for outdoor installation
• Designed for apartments, villas, offices, and gated communities
| System | Linux |
| Material | Aluminum Alloy |
| Color | Silver |
| Camera | 2M Pixels , Dual-lens HD camera |
| Resolution | 720 x 1280 |
| Screen | 5-inch High-definition IPS Display |
| Operation Method | Touchscreen + Mechanical Button |
| Face Capacity | Default 2,000, expandable to 20,000 |
| Card Capacity | Default 2,000, expandable to 20,000 |
| APP Authorization | Default 1, expandable up to 1,000 |
| Unlock Methods | Face recognition、IC card、Password unlock、QR code unlock、Mobile APP / WeChat Mini Program |
| Video | H.264 / H.265 / 720P / 1080P |
| Audio | G.711 |
| Network | Standard LAN、Optional 4G / Wi-Fi |
| Power Supply | DC 12V |
| Power Current | ≤600mA |
| Recognition Accuracy | 99.7% |
| Recognition Speed | ≤1 second |
| IP Level | IP65 |
| Working Temperature | -30°C ~ +55°C |
| Storage Temperature | -35°C ~ +60°C |
| Working Humidity | 10~90% RH |
| Installation | Embedded Installation |
| Dimension (mm) | 365 × 140 × 50 mm |
| Installation Size | 343 × 126 × 44 mm |
