JSL-I1-1 SIP Door Phone
JSL-I1-1 SIP Door Phone
• Modern Keypad with Backlight – New digital keypad design with color backlight ensures easy operation day or night.
• 2MP HDR Camera – High-definition imaging delivers sharp, clear video in all lighting conditions.
• Durable Outdoor Protection – Built to IP66 and IK07 standards, with wide temperature tolerance for reliable performance in harsh environments.
• Versatile Connectivity – Multiple interfaces allow seamless integration with different security devices.
• ONVIF Protocol Support – Ensures high flexibility and smooth compatibility with mainstream security platforms.
| Fornt Penel |
Aluminum |
| Color |
Grey |
| Screen |
Color backlight |
| Sensor |
1/2.9-inch，CMOS |
| Camera |
2M,Support infrared |
| Keyboard |
12 Numeric keys+4 Function keys |
| Viewing Angle |
120°(Horizontal) 60°(Vertical) |
| Output Video |
H.264 |
| Card Storage |
10000 pcs |
| Power Consumption |
PoE:1.71 - 6.96W;Adapter:1.52 - 6.26W |
| Power Support |
DC 12V/1A;PoE 802.3af Cass3 |
| Working Temperature |
-40℃ - +70℃ |
| Storage Temperature |
-40℃ - +70℃ |
| Size |
177.4 * 88 * 36.15mm |
| IP/IK Level |
IP66/IK07 |
| Protocols |
SIP 2.0 over UDP/TCP/TLS |
| Unlocking Method |
IC/ID Card，By DTMF Code，Remote door opening |
| Installation |
Wall-mounted;Flush-mounted(Need to Purchase Accessories Separately：EX102) |
• Luxurious Silver Aluminium alloy panel
• Up to 120 apartments
• Resistant to vandalism and outdoor conditions
• Basic control of an illuminated TFT display in 2.8/ 4.3 "in English / Different language
• Including the visitor's guidance in English / Different language
• Includes accessibility for the deaf
• Leaving an automatic notification to all tenants about changing the login code.
• High-quality IP color camera with WDR built-in 1080 line IP resolution for day and night
• A unique camera lens for our company 120 degrees WDR built-in anti-glare to see the entire entrance space is special for the disabled and children.
• Recording the visitors and leaving a message.
• Activation of an electric or electromagnetic lock
• Dry contact NO or NC
• On-time door opening direction with indelible memory,
• Maintains programming codes during power outages.
• Infrastructure 2 tendon 0.5
• Operating temperature -40 ℃ - + 50 ℃
• Convenient to operate by the tenant.
• Entry option by proximity reader
• Possibility of entry by a number of digit codes
• Option to open a door by a sticker for a mobile phone
Dimensions: width 115 length 334 depth 50 mm
| System | Linux |
| Front panel | Alum+Tempered Glass |
| Color | Black & Silver |
| Camera | CMOS; 4M Pixels |
| Light | White Light |
| Screen | 2.8-inch TFT LCD |
| Button Type | Mechanical Pushbutton |
| Capacity of Cards | ≤40,000 pcs |
| Speaker | 8Ω, 1.0W/2.0W |
| Microphone | -56dB |
| Power support | 12~48V DC |
| RS 485 Port | Support |
| Gate Magnet | Support |
| Door Button | Support |
| Standby Power Consumption | ≤4.5W |
| Max Power Consumption | ≤12W |
| Working Temperature | -40°C ~ +50°C |
| Storage Temperature | -40°C ~ +60°C |
| Working Humidity | 10~90% RH |
| IP Grade | IP54 |
| Interface | Power In; RJ45; RS485; 12V Out; Door release button; Door open detector; Relay out; |
| Installation | Embedded/Iron Gate |
| Resolution | 1280*720 |
| Dimension (mm) | 115*334*50 |
| Embedded Box Dimension (mm) | 113*335*55 |
| Working Current | ≤500mA |
| Door Entry | IC card(13.56MHz), ID card(125kHz), PIN code |
| Network | 10M/100M Auto-Ngegotiation |
| Horizontal Viewing Angles | 120° |
| Audio SNR | ≥25dB |
| Audio Distortion | ≤10% |
| Type / File name | Date | Download |
|---|---|---|
| JSL-I1-1 DataSheets | 2025-11-01 | Download PDF |
