JSL-I12 IP Villa Outdoor unit
JSL-I12 IP Villa Outdoor unit
• Supports Tuya IoT platform for remote video intercom and access control
• Enables real-time video viewing and two-way audio communication via mobile APP
• Supports remote door unlocking through APP or indoor smart terminal
• Touch sensing call button provides stable operation and modern user interaction
• Integrated 2 MP HDR camera delivers clear and balanced images
• Supports video recording and playback via mobile APP
• Supports IC card and NFC card access for local unlocking
• Adaptive infrared fill light supports night operation
• Supports TF card for local video storage
• Device sharing supports multi-user family access
• Supports QR code configuration for Wi-Fi models
• Supports LAN auto-discovery for wired network configuration
• Supports ONVIF protocol for third-party system integration
• IP65-rated housing supports outdoor and harsh environment deployment
| System | Linux |
| Platform | Tuya IoT |
| ONVIF | Supported |
| Image Sensor | 2 Megapixel |
| Video Encoding | H.264 / H.265 |
| HDR | Supported |
| Fill Light | Adaptive infrared fill light |
| Audio | Two-way audio |
| Call Method | One-key call to indoor terminal and mobile APP |
| Unlock Method | IC card / NFC card / APP / Indoor terminal |
| Motion Detection | Supported |
| Snapshot Capture | Supported |
| Video Recording | Supported |
| Network Interface | Ethernet (Optional Wi-Fi) |
| Network Mode | DHCP |
| Configuration Method | QR code (Wi-Fi) / LAN search (wired) |
| TF Card | Supported (not included) |
| Power Supply | DC 12V / 1A or PoE |
| Working Current | 400 mA |
| Working Temperature | -30℃ ~ +70℃ |
| Storage Temperature | -40℃ ~ +70℃ |
| Working Humidity | 10~90% RH |
| IP Grade | IP65 |
| Material | Aluminum |
| Installation | On-wall / In-wall |
| Dimension (mm) | 177.29 × 88 × 28.56 mm |
