JSL-I407AF 4MP IR Camera
JSL-I407AF 4MP IR Camera
• 4.0MP high-resolution output with 1/2.8" low illumination CMOS sensor
• Supports 4MP@20fps and 3MP@25fps for smooth, clear video streaming
• Equipped with 42 infrared LEDs
• Delivers night vision up to 30–40 meters in total darkness
• 2.8–12mm manual focus varifocal lens
• Easily adjustable for wide-angle or narrow monitoring needs
• Supports H.265 and H.264 dual-stream compression
• Saves bandwidth and storage while maintaining image quality
• Built-in AI algorithm for accurate human recognition
• Minimizes false alarms and enhances security response
• Sturdy metal housing for enhanced durability
• Weather-resistant, ideal for outdoor environments
• Product size: 230 × 130 × 120 mm
• Net weight: 0.7 kg – easy for transportation and installation
| Model | JSL-I407AF |
| Image Sensor | 1/2.8" CMOS, low illumination |
| Resolution | 4.0MP (2560×1440) / 3.0MP (2304×1296) |
| Frame Rate | 4.0MP @ 20fps, 3.0MP @ 25fps |
| Lens | 2.8–12mm manual varifocal lens |
| Infrared LEDs | 42 pcs |
| IR Distance | 30 – 40 meters |
| Compression Format | H.265 / H.264 |
| Smart Features | Human detection (AI-powered) |
| Housing Material | Metal shell |
| Ingress Protection | Weather-resistant (outdoor use) |
| Power Supply | 12V DC or PoE |
| Working Temperature | -40℃ to +60℃ |
| Packing Size(mm) | 230 × 130 × 120 mm |
| Net Weight | 0.7 kg |
