China JSL-I82NPR-FD Factory and Manufacturer

JSL-I82NPR-FD

Short Description:

JSL-I82NPR-FD is a parking entrance ALPR camera with high-definition, high-quality and high-performance. It can recognize more than 20 countries’license plates. Video trigger can be used alone without coil. In addition to license plates, more than 2900 brands and 11 types can also be recognized. It has the highest electrical protection level in China and has a wonderful ability to handle complex light. You can use SA-I20LPR to do all kinds of things in different systems, such as parking management, traffic control, targeted advertsing, auxiliary police.

Send email to us

Product Detail

Product Tags

Product Fetures

• Tech-based high precision LPR algorithm supports the camera can work in various harsh environment such as large angle, front/back lighting, raining and snowing. The speed, types and accuracy of recognition are the best of the industry
• Support unlicensed vehicle detection and non-motor vehicle filtering.
• Able to recognize different car types: small/medium/large, allowing to automatic charging
• Built-in black and white list management
• Free SDK; support multiple linking solutions such as the dynamic link library (DLL) and com components; support a variety of development languages like C, C++, C#, VB, Delphi, Java, etc

Specification

CPU	Hisilicom,pecialized license plate recognition chip
Sensor	1/2.8" CMOS Image Sensor
Minimum illumination	0.01Lux
Lens	6mm fixed focus lens
Built-in light	4 high-power LED white lights
Plate recognition accuracy	≥96%
Plate types	Overseas licence plate
Triggering mode	Video trigger,coil trigger
Image output	1080P(1920x1080),960P(1280x960),720P(1280x720),D1(704x576),CIF(352x288)
Picture output	2 mega-pixel JPEG
Video compression format	H.264 Hight Profile,Main Profile,Baseline,MJPEG
Network interface	10/100,RJ45
I/O	2 input & 2 output 3.5mm connecting terminals
Serial interface	2 x RS485
Audio interface	1 input & 1 output
SD card	Support SD2.0 standard Micro SD(TF)card with a maximum caoacity of 32G
Power supply	DC 12V
Power consumption	≤7.5W
Working temperature	-25℃~+70℃
Protection grade	IP66
Size(mm)	355(L)151(W)233(H)
Weight	2.7kg
