JSL-I88NPR-FD 2MP ANPR Camera
JSL-I88NPR-FD 2MP ANPR Camera
• Advanced Recognition: Supports over 20 countries’ license plates, 2900+ brands, and 11 vehicle types with ≥96% accuracy.
• High-Precision Algorithm: Reliable performance under large angles, strong backlight, rain, and snow.
• Vehicle Classification: Recognizes small, medium, and large vehicles for automatic charging.
• Additional Detection: Supports unlicensed vehicle detection and non-motor vehicle filtering.
• Integrated Management: Built-in black & white list functionality.
• Developer-Friendly: Free SDK; supports DLL & COM components; compatible with C/C++, C#, VB, Delphi, Java.
• Rugged & Reliable: IP66 protection, wide operating temperature (-25℃ ~ +70℃), suitable for outdoor deployment.
| Model | JSL-I88NPR-FD |
| Type | Parking Entrance ANPR Camera |
| CPU | Hisilicon, specialized license plate recognition chip |
| Image Sensor | 1/3" CMOS Image Sensor |
| Minimum Illumination | 0.01 Lux |
| Lens | 6mm fixed focus lens |
| Built-in Light | 4 high-power LED white lights |
| Plate Recognition Accuracy | ≥96% |
| Plate Types | Overseas license plates |
| Trigger Mode | Video trigger, coil trigger |
| Image Output | 1080p (1920×1080), 960p (1280×960), 720p (1280×720), D1 (704×576), CIF (352×288) |
| Picture Output | 2MP JPEG |
| Video Compression | H.264 (High/Main/Baseline profiles), MJPEG |
| Network Interface | 10/100 Mbps, RJ45 |
| I/O | 2 input & 2 output, 3.5mm connecting terminals |
| Serial Interface | 2 × RS485 |
| Audio Interface | 1 input & 1 output |
| Storage | Supports SD 2.0 microSD (TF) card, up to 32GB |
| Power Supply | AC 220V & DC 12V |
| Power Consumption | ≤7.5W |
| Workting Temperature | -25℃ ~ +70℃ |
| IP Level | IP66 |
| Size | 452 (L) × 148 (W) × 120 (H) mm |
| Weight | 2.7kg |
