JSL-MB702 3/5/8MP Motorized Zoom Bullet Camera

Short Description:

JSL-MB702 3/5/8MP Motorized Zoom Bullet Camera delivers High-Quality Day and Night Surveillance with selectable 3MP, 5MP, and 8MP Sensors. It features Motorized Zoom, Humanoid Detection, IR Night Vision up to 40m, and H.265 Video Compression for efficient bandwidth and storage usage, making it ideal for Outdoor and Large-Area Monitoring such as warehouses, parking lots, and parks.

Send email to us

Product Detail

Product Tags

Product Fetures

• High-performance 3MP/5MP/8MP CMOS sensor with motorized zoom lens.
• Built-in humanoid detection algorithm with up to 5-person simultaneous detection.
• IR LED night vision up to 30–40 meters with auto ICR D&N switching.
• Supports H.265/H.264/S.265 video compression for bandwidth and storage efficiency.
• 3D DNR + D-WDR for clearer images under challenging lighting.
• Optional PoE power supply and adaptive 10/100M RJ45 network port.
• HTTPS encryption, password protection, and ONVIF 2.4 compliance.
• IP66-rated waterproof design suitable for extreme weather and outdoor use.

Specification

Sensor	1/2.9" 3MP low-illumination CMOS	1/2.7" 5MP low-illumination CMOS	1/2.8" 8MP low-illumination CMOS
Resolution	2304×1296@20fps; 1920×1080@25fps	2592×1904@20fps; 2560×1920@25fps; 2304×1296@25fps; 1920×1080@25fps	3840×2160@15fps; 2592×1904; 2560×1440; 2304×1296; 1920×1080@25fps
Sub Stream	D1, 864×480, VGA, Q720P, CIF, QVGA	D1, 864×480, VGA, Q720P, CIF, QVGA	D1, 864×480, VGA, Q720P, CIF, QVGA
Illumination	Color: 0.001Lux; B/W: 0Lux (IR on)	Color: 0.001Lux; B/W: 0Lux (IR on)	Color: 0.001Lux; B/W: 0Lux (IR on)
WDR	D-WDR	D-WDR	D-WDR
3D DNR	Off/Low/Middle/High/Higher	Off/Low/Middle/High/Higher	Off/Low/Middle/High/Higher
Lens	2.8–12mm motorized, ∅14 ports	2.8–12mm motorized, ∅14 ports	2.8–12mm motorized, ∅14 ports
IR LEDs	4 pcs	4 pcs	4 pcs
IR Distance	Up to 30–40m	Up to 30–40m	Up to 30–40m
Video	S.265 / H.265 / H.264	S.265 / H.265 / H.264	S.265 / H.265 / H.264
Audio	1CH optional	1CH optional	1CH optional
Humanoid Detection	≤5 persons, ≥40×40 pixel	≤5 persons, ≥40×40 pixel	≤5 persons, ≥40×40 pixel
Detection Frame Rate	5fps	5fps	5fps
Onvif	ONVIF 2.4, Slink, (GB28181 optional)	ONVIF 2.4, Slink, (GB28181 optional)	ONVIF 2.4, Slink, (GB28181 optional)
Protocols	TCP/IP, UDP, HTTP, HTTPS, DHCP, RTSP, DDNS, NTP, PPPOE, UPNP, SMTP	TCP/IP, UDP, HTTP, HTTPS, DHCP, RTSP, DDNS, NTP, PPPoE, UPNP, SMTP	TCP/IP, UDP, HTTP, HTTPS, DHCP, RTSP, DDNS, NTP, PPPoE, UPNP, SMTP
Network	RJ45 10/100M adaptive	RJ45 10/100M adaptive	RJ45 10/100M adaptive
Power Supply	DC12V; external PoE optional (802.3af/at)	DC12V; external PoE optional (802.3af/at)	DC12V; external PoE optional (802.3af/at)
Power Consumption	<15W	<15W	<15W
Working Temperature	-10℃ ~ 60℃	-10℃ ~ 60℃	-10℃ ~ 60℃
Humidity	<90% RH	<90% RH	<90% RH
IP Level	IP66	IP66	IP66
Dimension (mm)	312.2 × 88.5 × 79.3 mm	312.2 × 88.5 × 79.3 mm	312.2 × 88.5 × 79.3 mm
Weight	960 g	960 g	960 g
