China JSL-MD107 4/5MP Infrared Dome Network Camera Factory and Manufacturer

JSL-MD107 4/5MP Infrared Dome Network Camera

Short Description:

The JSL-MD107 is a high-performance 4MP/5MP infrared dome network camera designed for reliable security monitoring in both indoor and outdoor environments. It features a low-illumination CMOS sensor that ensures clear and detailed images day and night. With built-in humanoid detection, the camera accurately identifies human targets while minimizing false alarms. Its efficient H.265 compression reduces bandwidth and storage consumption, and optional PoE simplifies installation. With an IP66-rated housing, the JSL-MD107 is well-suited for warehouses, corridors, parking areas, retail spaces, and various commercial applications

Send email to us

Product Detail

Product Tags

Product Fetures

• High-performance CMOS sensor for clear and stable day/night monitoring
• Built-in humanoid detection with reduced false alarms
• Efficient H.265 encoding lowers bandwidth and storage usage
• IR illumination up to 20m for reliable night vision
• Optional PoE for simplified installation and wiring
• Supports Onvif and major network protocols for flexible integration
• IP66 protection for harsh indoor/outdoor environments

Specification

Sensor	1/2.9" 4MP low-illumination CMOS	1/2.8" 4MP low-illumination CMOS	1/2.8" 5MP low-illumination CMOS
Resolution	2560×1440@20fps / 2048×1536@20fps / 1080P@25fps	2560×1440@20fps / 2048×1536@20fps / 1080P@25fps	2592×1904 / 2560×1440@20fps / 2304×1296@20fps / 1080P@25fps
Illumination	Color: 0.01Lux / B&W: 0Lux (IR on)	Color: 0.01Lux / B&W: 0Lux	Color: 0.01Lux / B&W: 0Lux
Sub-stream	D1 / 864×480 / VGA / 640×360 / CIF / QVGA	D1 / 864×480 / VGA / 640×360 / CIF / QVGA	D1 / 864×480 / VGA / 640×360 / CIF / QVGA
WDR	D-WDR	D-WDR	D-WDR
3D DNR	Off/Low/Middle/High/Higher	Off/Low/Middle/High/Higher	Off/Low/Middle/High/Higher
Lens	4mm (M12)	4mm (M12)	4mm (M12)
IR LEDs	12 pcs	12 pcs	12 pcs
IR Distance	Up to 15–20 m	Up to 15–20 m	Up to 15–20 m
Video	S.265 / H.265 / H.264	S.265 / H.265 / H.264	S.265 / H.265 / H.264
Audio	Not supported	Not supported	Not supported
Bitrate	1024Kbps–8000Kbps	1024Kbps–8000Kbps	1024Kbps–8000Kbps
Humanoid Detection	≤5 persons, up to 5fps	≤5 persons, 5fps detection	≤5 persons, 5fps detection
Onvif	Onvif / Slink / GB28181 (opt.)	Onvif / Slink / GB28181 (opt.)	Onvif / Slink / GB28181 (opt.)
Protocols	TCP/IP, UDP, HTTP, HTTPS, DHCP, RTSP, DDNS, NTP, PPPOE, UPNP, SMTP	TCP/IP, UDP, HTTP, HTTPS, DHCP, RTSP, DDNS, NTP, PPPoE, UPNP, SMTP	TCP/IP, UDP, HTTP, HTTPS, DHCP, RTSP, DDNS, NTP, PPPoE, UPNP, SMTP
Network	RJ45 10/100M adaptive	RJ45 10/100M adaptive	RJ45 10/100M adaptive
Power Supply	DC12V / optional PoE	DC12V / optional PoE	DC12V / optional PoE
Power Consumption	<15W	<15W	<15W
Working Temperature	-10℃ ~ 60℃	-10℃ ~ 60℃	-10℃ ~ 60℃
Humidity	<90% RH	<90% RH	<90% RH
IP Level	IP66	IP66	IP66
Dimension (mm)	109 × 109 × 63 mm	109 × 109 × 63 mm	109 × 109 × 63 mm
Weight	480 g	480 g	480 g
