JSL-MD201 3/5/8MP Motorized Zoom Dome Camera

Short Description:

The JSL-MD201 delivers high-resolution surveillance in 3MP, 5MP, and 8MP options, paired with a 2.8–12mm motorized zoom lens for flexible monitoring coverage. Its built-in humanoid detection algorithm increases security accuracy, while advanced H.265 encoding significantly reduces bandwidth and storage usage. With strong night vision, IP66 protection, and optional PoE, it is ideal for professional indoor and outdoor applications.

Send email to us

Product Detail

Product Tags

Product Fetures

• High-performance 3MP / 5MP / 8MP CMOS sensor with enhanced low-light capability
• Motorized 2.8–12mm zoom lens for wide-range monitoring flexibility
• Intelligent humanoid detection supporting up to 5 targets simultaneously
• H.265/S.265 video compression for bandwidth and storage savings
• 30pcs IR LEDs providing 30–40m night vision with ICR day/night switching
• Digital WDR, 3D DNR, defog and image optimization settings for various environments
• Supports HTTPS encryption, ONVIF 2.4, multiple network protocols, and security protections
• IP66 outdoor rating with optional PoE for simplified installation

Specification

Sensor	1/2.9" 3MP low-illumination CMOS	1/2.7" 5MP low-illumination CMOS	1/2.8" 8MP low-illumination CMOS
Resolution	2304×1296 @20fps; 1920×1080 @25fps	2592×1904 @20fps; 2560×1920 @25fps; 2304×1296 @25fps; 1920×1080 @25fps	3840×2160 @15fps; 2592×1904; 2560×1440; 2304×1296; 1920×1080 @25fps
Sub Stream	D1, 864×480, VGA, Q720P, CIF, QVGA	D1, 864×480, VGA, Q720P, CIF, QVGA	D1, 864×480, VGA, Q720P, CIF, QVGA
Illumination	Color 0.01 Lux; B/W 0 Lux with IR	Color 0.01 Lux; B/W 0 Lux with IR	Color 0.01 Lux; B/W 0 Lux with IR
WDR	WDR	D-WDR	D-WDR
3D DNR	Off/Low/Middle/High/Higher	Off/Low/Middle/High/Higher	Off/Low/Middle/High/Higher
Defog	Off/Low/Middle/High	Off/Low/Middle/High	Off/Low/Middle/High
Mirror	Off/H-mirror/V-mirror/180° flip	Off/H-mirror/V-mirror/180° flip	Off/H-mirror/V-mirror/180° flip
Lens	2.8–12mm motorized (Ø14 port)	2.8–12mm motorized (Ø14 port)	2.8–12mm motorized (Ø14 port)
IR LEDs	30pcs IR LED	30pcs IR LED	30pcs IR LED
IR Distance	Up to 30–40m	Up to 30–40m	Up to 30–40m
Video	S.265 / H.265 / H.264	S.265 / H.265 / H.264	S.265 / H.265 / H.264
Audio	1CH optional	1CH optional	1CH optional
Humanoid Detection	≤5 people, ≥99% accuracy, ≤1s response	≤5 people, ≥99% accuracy, ≤1s response	≤5 people, ≥99% accuracy, ≤1s response
Onvif	Onvif / Slink / GB28181 (opt.)	Onvif / Slink / GB28181 (opt.)	Onvif / Slink / GB28181 (opt.)
Protocols	TCP/IP, UDP, HTTP, HTTPS, DHCP, RTSP, DDNS, NTP, PPPOE, UPNP, SMTP	TCP/IP, UDP, HTTP, HTTPS, DHCP, RTSP, DDNS, NTP, PPPoE, UPNP, SMTP	TCP/IP, UDP, HTTP, HTTPS, DHCP, RTSP, DDNS, NTP, PPPoE, UPNP, SMTP
Network	RJ45 10/100M adaptive	RJ45 10/100M adaptive	RJ45 10/100M adaptive
Power Supply	DC12V/2A (PoE optional)	DC12V/2A (PoE optional)	DC12V/2A (PoE optional)
Power Consumption	<15W	<15W	<15W
Working Temperature	-10℃ ~ 60℃	-10℃ ~ 60℃	-10℃ ~ 60℃
Humidity	<90% RH	<90% RH	<90% RH
IP Level	IP66	IP66	IP66
Dimension (mm)	140 × 140 × 101 mm	140 × 140 × 101 mm	140 × 140 × 101 mm
Weight	850 g	850 g	850 g
