JSL-PB605 3/5/8MP Dual-Light Full-Color Bullet Camera

Short Description:

The JSL-PB605 is a high-performance dual-light full-color bullet camera, supporting 3MP, 5MP, and 8MP resolutions. It features humanoid detection, dual-light night vision, H.265 compression, and POE options, ideal for warehouses, parking lots, parks, and other surveillance scenarios.

Send email to us

Product Detail

Product Tags

Product Fetures

• Dual-light full-color/infrared night vision
• High-performance 3/5/8MP CMOS sensor
• Humanoid detection (≤5 people, 5fps, tracking supported)
• H.265 video compression, bandwidth and storage efficient
• Low stream code & ROI strengthen encoding
• POE support (optional)
• IP66 weatherproof design
• RJ45 10/100M adaptive network port

Specification

Sensor	1/2.9" 3MP low-illumination CMOS	1/2.7" 5MP low illumination CMOS	1/2.8" 8MP low illumination CMOS
Resolution	2304×1296 @20fps	2592×1904 @20fps	3840×2160 / 2592×1904 / 2560×1440 / 2304×1296 / 1920×1080 @25fps
Illumination	Color 0.01 Lux; B/W 0 Lux with IR	Color 0.01 Lux; B/W 0 Lux with IR	Color 0.01 Lux; B/W 0 Lux with IR
WDR	D-WDR	D-WDR	D-WDR
3D DNR	Off/Low/Middle/High/Higher	Off/Low/Middle/High/Higher	Off/Low/Middle/High/Higher
Lens	4mm, M12 ports	4mm, M12 ports	4mm, M12 ports
IR LEDs	4 pcs	4 pcs	4 pcs
IR Distance	Up to 15–20m	Up to 15–20m	Up to 15–20m
Video	S.265 / H.265 / H.264	S.265 / H.265 / H.264	S.265 / H.265 / H.264
Audio	Not supported	Not supported	Not supported
Humanoid Detection	≤5 persons, 5fps, tracking supported	≤5 persons, 5fps, tracking supported	≤5 persons, 5fps, tracking supported
Onvif	Onvif / Slink / GB28181 (opt.)	Onvif / Slink / GB28181 (opt.)	Onvif / Slink / GB28181 (opt.)
Protocols	TCP/IP, UDP, HTTP, HTTPS, DHCP, RTSP, DDNS, NTP, PPPOE, UPNP, SMTP	TCP/IP, UDP, HTTP, HTTPS, DHCP, RTSP, DDNS, NTP, PPPoE, UPNP, SMTP	TCP/IP, UDP, HTTP, HTTPS, DHCP, RTSP, DDNS, NTP, PPPoE, UPNP, SMTP
Network	RJ45 10/100M adaptive	RJ45 10/100M adaptive	RJ45 10/100M adaptive
Power Supply	DC12V; POE optional (802.3af/at)	DC12V; POE optional (802.3af/at)	DC12V; POE optional (802.3af/at)
Power Consumption	<15W	<15W	<15W
Working Temperature	-10℃ ~ 60℃	-10℃ ~ 60℃	-10℃ ~ 60℃
Humidity	<90% RH	<90% RH	<90% RH
IP Level	IP66	IP66	IP66
Dimension (mm)	171 × 63 × 63 mm	171 × 63 × 63 mm	171 × 63 × 63 mm
Weight	450 g	450 g	450 g
