• Five-Camera Integrated Design: Combines four fixed-focus cameras with one motorized PTZ camera in a single device.
• 25MP Combined Imaging: Uses five 5MP imaging sensors for panoramic and zoom surveillance.
• 240° Panoramic Monitoring: Four fixed-focus cameras provide wide-area coverage to help reduce blind spots.
• 20X Optical Zoom: The 4.7–94mm zoom lens enables detailed observation of distant targets.
• AI Human Recognition: Supports human detection and intelligent intrusion analysis.
• Automatic Target Tracking: Warning lines and warning areas can trigger linked tracking and zooming.
• Precision PTZ Control: Supports smooth motorized movement and accurate positioning.
• High-Speed Rotation: Listed horizontal rotation speed reaches 240°/s.
• Starlight Low-Light Imaging: GC4653 sensors support image capture in challenging lighting conditions.
• Color Night Vision: Combines warm-light illumination and infrared LEDs for nighttime surveillance.
• IP66 Outdoor Protection: Designed for outdoor environments requiring dust and water-jet protection.
• Remote Mobile Access: Supports mobile app access as specified by the manufacturer.
• Wide Application Range: Suitable for perimeter security, industrial facilities, parking areas, logistics centers, and commercial properties.
| Model | JSL-PD20 |
| Product Type | Panoramic Automatic Tracking PTZ Camera |
| Imaging Resolution | 25MP total, 5 × 5MP sensors |
| Maximum Resolution | 2592 × 1944, as specified |
| Camera | 4 fixed-focus cameras + 1 PTZ camera |
| Imaging Platform | 5 × SigmaStar 377 + GC4653 sensors, as specified |
| Camera Lens | 6mm, F1.0 |
| PTZ Zoom Lens |
4.7–94mm |
| Optical Zoom | 20X |
| Fixed Camera Coverage | 240° panoramic monitoring |
| Intelligent Analysis | Supported |
| Human Recognition | Supported |
| Intrusion Detection | Supported |
| Automatic Tracking | Supported |
| Warning Line / Area | Supported |
| Tracking Linkage | Linked tracking and zooming |
| Vertical Speed | 0.05°–100°/s |
| Illumination | 4 warm-light units + 9 IR LEDs, as specified |
| Night Vision | Starlight low-light imaging and color night vision |
| Maximum Distance | 150m, conditions to be confirmed |
| Microphone | Built-in |
| TF Storage | 64GB |
| Interface | 1 × RJ45 |
| Protection | IP66 |
| Dimension (mm) | 29 × 29 × 38mm |
