JSL-R3220 2HDD 20ch AI NVR

Short Description:

The JSL-R3220 is a versatile 20-channel AI NVR that balances high-capacity storage with advanced intelligent analytics. Supporting up to 16MP recording and dual 10TB HDDs, it provides a robust platform for high-resolution surveillance. Its built-in AI engine features Face Recognition, Perimeter Protection, and Smart Motion Detection (SMD), enabling proactive security management. With 4K HDMI output, S+265 compression efficiency, and plugin-free browser access, the JSL-R3220 is the professional choice for projects requiring more than standard channel counts without the footprint of an enterprise server.

Send email to us

Product Detail

Product Tags

Product Fetures

• Supports up to 20-channel IP camera access
• Maximum 16MP ultra-HD recording
• 160Mbps incoming bandwidth (120Mbps with AI enabled)
• 4K HDMI video output (3840×2160)
• Dual HDD design, up to 10TB per disk
• Built-in AI by NVR & AI by Camera
• Face detection and face recognition supported
• Up to 20,000 face images library capacity
• Perimeter protection & smart motion detection (4CH AI by NVR)
• People counting and heatmap statistics
• Safety helmet & electric bicycle detection
• Smoke & fire detection support
• 16-channel synchronous playback
• 1×Gigabit network interface
• Alarm I/O supported (4-in / 1-out)
• ONVIF Profile S/T/G compatible

Specification

Video Input	20CH IP
Max Resolution	16MP
Incoming Bandwidth	160 Mbps (120 Mbps AI On)
Outgoing Bandwidth	80 Mbps
Video Compression	S+265 / H.265 / H.264
Playback	Up to 16CH
AI by NVR	Face Recognition / Perimeter / SMD (4CH)
AI by Camera	Face Detection / People Counting / Heatmap
Face Library	Up to 10 Libraries, 20,000 Images
Smart Search	Face Search / Behavior Search / Thermographic Retrieval
AI Events	Helmet / Fire & Smoke / Crowd / Temperature
HDD Interface	2×SATA
Max Capacity	Up to 10TB per HDD
Disk Group	1×HDMI (Up to 4K), 1×VGA
Network Interface	1×RJ45 (10/100/1000 Mbps)
Audio	1×Audio In, 1×Audio Out
Alarm I/O	4×Input, 1×Relay Output
USB	2×USB 2.0
Power Supply	DC 12V
Operating Temperature	-10°C ~ +55°C
Dimensions	341 × 280 × 47 mm
Weight	1.6 kg
