China JSL-R3240 2HDD 40ch AI NVR Factory and Manufacturer

JSL-R3240 2HDD 40ch AI NVR

Short Description:

The JSL-R3240 40CH AI NVR is a flagship intelligent video management platform built for large-scale and mission-critical surveillance systems. Supporting up to 40 IP cameras with 16MP ultra-HD recording and 400Mbps bandwidth, it delivers powerful AI analytics including face recognition, video structuralization, license plate recognition, perimeter protection, and people counting. With dual Gigabit network ports, 4K output, extensive alarm I/O, and enterprise-grade performance, the JSL-R3240 ensures scalable, intelligent, and reliable security management for commercial, industrial, and city-level applications.

Send email to us

Product Detail

Product Tags

Product Fetures

• Supports up to 40-channel IP camera access
• Maximum 16MP ultra-HD recording
• 400Mbps incoming & outgoing bandwidth (200Mbps AI enabled)
• 4K HDMI output (3840×2160 @60Hz)
• Dual Gigabit Ethernet ports
• Dual HDD design, up to 10TB per disk
• Advanced S+265 / H.265 compression
• AI by NVR and AI by Camera supported
• 8CH face recognition (video stream)
• Up to 100,000 face image capacity
• Video structuralization (8CH @1080P)
• License plate recognition supported
• Perimeter protection up to 24CH
• Smart motion detection up to 32CH
• People counting & heatmap analysis
• Fire & smoke detection supported
• 16-channel synchronous playback
• 16 alarm inputs & 4 relay outputs
• RS232 & RS485 industrial interfaces

Specification

Video Input	40CH IP
Max Resolution	16MP
Incoming Bandwidth	400 Mbps (200 Mbps AI On)
Outgoing Bandwidth	400 Mbps (200 Mbps AI On)
Video Compression	S+265 / H.265 / H.264
Playback	Up to 16CH
Face Recognition	8CH Video / 32CH Image
Face Library	Up to 20 Libraries, 100,000 Images
Perimeter Protection	Up to 24CH
Smart Motion Detection	Up to 32CH
Video Structuralization	8CH @1080P
LPR	Supported
Smart Search	Face / Behavior / License Plate / Thermographic
HDD Interface	2×SATA
Max Capacity	Up to 10TB per HDD
Disk Group	2 Groups
Video Output	1×HDMI (Up to 4K@60Hz), 1×VGA
Network Interface	2×RJ45 (10/100/1000 Mbps)
Audio	1×Audio In, 1×Audio Out
Alarm I/O	16×Input, 4×Relay Output
USB	1×USB2.0, 1×USB3.0
Serial Port	RS232 / RS485
Power Supply	DC 12V
Operating Temperature	-10°C ~ +55°C
Dimensions	440 × 277 × 47.5 mm
Weight	2.25 kg
