One-Button Villa Outdoor Station JSL-15: Smart Access with HD Visual Communication
One-Button Villa Outdoor Station JSL-15: Smart Access with HD Visual Communication
• Elegant silver aluminum alloy panel
• Ideal for single-family homes and villas
• Rugged design, IP54 and IK04 rated for outdoor and vandal-resistant performance
• Equipped with a 2MP HD camera (up to 1080p resolution) with white light for enhanced night vision
• 60° (H) / 40° (V) wide viewing angle for clear entrance monitoring
• Embedded Linux system with 16MB Flash and 64MB RAM for stable operation
• Supports remote configuration via Web interface
• Built-in anti-theft alarm (equipment removal detection)
• Built-in speaker and microphone with G.711 audio codec
• Supports electric or electromagnetic lock control via dry contact (NO/NC)
• Includes relay port, RS485, door magnet sensor and lock release interfaces
• Wall-mounted installation with included mounting plate and screws
• Supports network protocols: TCP/IP, UDP, HTTP, DNS, RTP
| System | Embedded Linux system |
| Front panel | Alum+Tempered Glass |
| Color | Silver |
| Camera | 2.0 million pixels, 60°(H) / 40°(V) |
| Light | White Light |
| Capacity of Cards | ≤30,000 pcs |
| Speaker | Built-in loudspeaker |
| Microphone | -56±2dB |
| Power support | 12~24V DC |
| RS 485 Port | Support |
| Gate Magnet | Support |
| Door Button | Support |
| Standby Power Consumption | ≤3W |
| Max Power Consumption | ≤6W |
| Working Temperature | -30°C ~ +60°C |
| Storage Temperature | -40°C ~ +70°C |
| Working Humidity | 10~95% RH |
| IP Grade | IP54 |
| Interface | Power Port; RJ45; RS485; Relay Port; Lock Release Port; Door Magnetism Port |
| Installation | Wallmounted |
| Dimension (mm) | 79*146*45 |
| Embedded Box Dimension (mm) | 77*152*52 |
| Network | TCP/IP, UDP, HTTP, DNS, RTP |
| Horizontal Viewing Angles | 60° |
| Audio SNR | ≥25dB |
| Audio Distortion | ≤10% |
