China JSL-MD103 3/5/8MP Dual-light Full-Color Turret Camera Factory and Manufacturer

JSL-MD103 3/5/8MP Dual-light Full-Color Turret Camera

Short Description:

JSL-MD103 is a dual-light full-color turret camera designed for stable day-and-night monitoring with selectable 3MP, 5MP, or 8MP high-performance CMOS sensors. It supports humanoid detection, H.265 compression, IR/warm-light switching, and low-bitrate encoding for efficient and accurate surveillance. Ideal for warehouses, parking lots, bars, parks, and other environments requiring reliable full-color performance in low-light conditions.

Send email to us

Product Detail

Product Tags

Product Fetures

• High-performance 3MP/5MP/8MP CMOS sensor for clear full-color imaging.
• Built-in humanoid detection algorithm with up to 5-person simultaneous detection.
• Dual-light mode: infrared, warm-light full-color, and smart switching.
• Supports H.265/H.264/S.265 compression for reduced bandwidth and storage.
• 3D DNR + D-WDR for noise reduction and improved dynamic range.
• Optional PoE power supply and 10/100M adaptive RJ45 network port.
• Secure access with HTTPS encryption, password protection, and ONVIF 2.4 support.
• IP66 weatherproof design suitable for indoor and outdoor environments.

Specification

Sensor	1/2.9" 3MP low-illumination CMOS	1/2.7" 5MP low-illumination CMOS	1/2.8" 8MP low-illumination CMOS
Resolution	2304×1296@20fps; 1920×1080@25fps	2592×1904; 2560×1440@20fps; 2304×1296@20fps; 1920×1080@25fps	3840×2160@15fps; 2592×1904; 2560×1440; 2304×1296; 1920×1080@25fps
Sub Stream	D1, 864×480, VGA, Q720P, CIF, QVGA	D1, 864×480, VGA, Q720P, CIF, QVGA	D1, 864×480, VGA, Q720P, CIF, QVGA
Illumination	Color 0.01 Lux; B/W 0 Lux with IR	Color 0.01 Lux; B/W 0 Lux with IR	Color 0.01 Lux; B/W 0 Lux with IR
WDR	D-WDR	D-WDR	D-WDR
3D DNR	Off/Low/Middle/High/Higher	Off/Low/Middle/High/Higher	Off/Low/Middle/High/Higher
Lens	4mm M12	4mm M12	4mm M12
IR LEDs	6pcs dual-light LED	6pcs dual-light LED	6pcs dual-light LED
IR Distance	Up to 15–20m	Up to 15–20m	Up to 15–20m
Video	S.265 / H.265 / H.264	S.265 / H.265 / H.264	S.265 / H.265 / H.264
Audio	1CH optional G.711u / 64Kbps	1CH optional G.711u / 64Kbps	1CH optional G.711u / 64Kbps
Humanoid Detection	≤5 persons, 5fps, tracking supported	≤5 persons, 5fps, tracking supported	≤5 persons, 5fps, tracking supported
Onvif	ONVIF 2.4, Slink, (GB28181 optional)	ONVIF 2.4, Slink, (GB28181 optional)	ONVIF 2.4, Slink, (GB28181 optional)
Protocols	TCP/IP, UDP, HTTP, HTTPS, DHCP, RTSP, DDNS, NTP, PPPOE, UPNP, SMTP	TCP/IP, UDP, HTTP, HTTPS, DHCP, RTSP, DDNS, NTP, PPPoE, UPNP, SMTP	TCP/IP, UDP, HTTP, HTTPS, DHCP, RTSP, DDNS, NTP, PPPoE, UPNP, SMTP
Network	RJ45 10/100M adaptive	RJ45 10/100M adaptive	RJ45 10/100M adaptive
Power Supply	DC12V; external PoE optional (802.3af/at)	DC12V; external PoE optional (802.3af/at)	DC12V; external PoE optional (802.3af/at)
Power Consumption	<15W	<15W	<15W
Working Temperature	-10℃ ~ 60℃	-10℃ ~ 60℃	-10℃ ~ 60℃
Humidity	<90% RH	<90% RH	<90% RH
IP Level	IP66	IP66	IP66
Dimension (mm)	114.5 × 114.5 × 97.3 mm	114.5 × 114.5 × 97.3 mm	114.5 × 114.5 × 97.3 mm
Weight	500 g	500 g	500 g
