JSL-NC506MC-T35-AD Image Recognition Camera
JSL-NC506MC-T35-AD Image Recognition Camera
• Metal front housing with durable design
• PoE supported, easy installation
• Intelligent dual-light system (IR + warm light) with full-color night vision
• Human detection and area intrusion with sound & light alarm
• Advanced AI analytics: regional people counting, smoking & phone call detection
• Optional AI algorithms: helmet, reflective clothing, off-duty detection
• Built-in high-performance GPU with SONY image sensor
• H.265 / H.264 / MJPEG encoding with WDR, 3D DNR, defog, and ROI support
• Built-in voice broadcasting and two-way audio, supports external amplifier
• Local storage via built-in micro SD card, HK protocol compatible, optional 4G
| Material | Plastic + Metal |
| Resolution | 2880 * 1620 |
| Lens | F1.6 4mm 5MP |
| Sensor | 1/2.7” 5MP CMOS:Fire Sensor：4.3um Main Detect + 5.0um Compare |
| FOV | Horizontal 90°，Vertical 48° |
| Distance | 30m |
| Warm Light | 4 pcs |
| Audio | Built-in Microphone |
| WDR | 140dB |
| TF Storage |
Built-in 64G TF Card (Default)
Max. support up to 256G (optional).
|
| Protocol | HTTP、HTTPS、TCP/IP、UDP、RTP、FTP、RTCP、RTSP、NTP、DHCP、DNS、DDNS、SNMP、SSL/TLS、WebSocket、UPNP、PPPOE |
| 4G | Support |
| Browse |
IE10，IE11，Edge，Chrome，Firefox
|
| Interface |
1pcs RJ45, 1ch Alarm input/1ch Alarm output, 1ch RCA Audio output
|
| Facial Detection |
Support
|
| Detect Range |
15-20m
|
| Power Supply |
DC12V / POE
|
| Size |
109 * 109 * 90mm
|
| Weight |
600g
|
