JSL-SP800-W4G 4MP 4G PTZ Speed Dome Camera
JSL-SP800-W4G 4MP 4G PTZ Speed Dome Camera
• 4MP High-Resolution Imaging: Maximum resolution of 2688 × 1520 for detailed surveillance footage.
• CMOS Image Sensor: Features a 1/2.8-inch 4MP CMOS sensor.
• Flexible Lens Options: Available with 4mm or 6mm lens configurations.
• 100dB WDR: Helps improve image visibility in scenes with contrasting light levels.
• Warm-Light Illumination: Six warm-light LEDs provide supplementary illumination.
• Built-in Microphone: Supports audio capture for compatible monitoring applications.
• Human Detection: Supports human detection to assist security monitoring.
• Face Detection: Provides face detection functionality for supported surveillance applications.
• Multiple Network Protocols: Supports IPv4, IPv6, HTTP, ONVIF, SIP, RTSP, WebRTC, TCP, UDP, DHCP, and other protocols.
• Flexible System Integration: Includes alarm I/O, RS485, audio output, and an RJ45 network interface.
| Model | JSL-SP800-W4G |
| Product Type | 4MP Speed Dome Camera |
| Max. Resolution | 2688 × 1520 |
| Sensor Type | 1/2.8-inch 4MP CMOS Sensor |
| Lens | 4mm / 6mm |
| Lens Aperture | F1.6 |
| Warm Light | 6 pcs |
| Audio | Built-in Microphone |
| WDR | 100dB |
| Human Detection | Supported |
| Face Detection | Supported |
| Network Protocols | IPv4, IPv6, HTTP, ONVIF, SIP, RTSP, WebRTC, Modbus, TCP, UDP, DHCP, and others |
| Network Interface | 1 × RJ45 |
| Alarm Interface | 1-channel Alarm Input / 1-channel Alarm Output |
| Audio Interface | 1 × Audio Output |
| Power Supply | 12V DC |
| Applications | Commercial Security, Industrial Surveillance, Parking Areas, Campuses, Public Facilities |
