China JSL-SV1 Villa Outdoor Station Factory and Manufacturer

JSL-SV1 Villa Outdoor Station

Short Description:

The JSL-SV1 Outdoor SIP Door Station is designed for villas and upscale residences, delivering HD video intercom and smart access control in one elegant unit. Featuring a high-definition camera for clear visitor identification, a capacitive touch call button with illuminated ring, and two-way audio communication, it ensures security with style. Built with weather-resistant housing and integrated night vision, the JSL-SV1 provides reliable 24/7 performance in any outdoor environment, making it the ideal choice for modern smart home security.

Send email to us

Product Detail

Product Tags

Product Fetures

• HD Camera for crystal-clear visitor video
• Capacitive Touch Call Button with illuminated ring for effortless operation
• Two-Way Audio Communication with indoor monitors or mobile apps
• Weather-Resistant Housing for outdoor durability
• Night Vision with infrared LEDs for low-light clarity

Specification

System	Linux
Color	Black
Camera	2MP:60°(H)/40°(V)
Light	White Light
Button Type	Mechanical Pushbutton
Capacity of Cards	≤30,000 pcs
Speaker	Built-in loudspeaker
Microphone	-56dB
Power support	12~24V DC
Door Button	Support
Working Temperature	-30°C ~ +60°C
Storage Temperature	-40°C ~ +70°C
Working Humidity	10~95% RH
IP Grade	IP54
Interface	Power In; RJ45; RS485; 12V Out; Door release button; Door open detector; Relay out;
Installation	Wallmounted
Dimension (mm)	5912152
Network	TCP/IP, UDP, HTTP, DNS, RTP
