JSL63 SIP Multi-Button Door Phone – Smart Video Intercom with Access Control

Short Description:

The JSL63 SIP Multi-Button Door Phone integrates intercom, access control, and security management into a single intelligent device. Featuring a durable IP66 and IK07-rated metal body, it ensures reliable operation even in harsh outdoor environments.

Equipped with five quick-call buttons and a 2MP HD camera, it supports one-touch audio and video communication, providing users with convenient and secure entry management. The JSL63 supports multiple unlocking methods, including RFID cards, remote unlock, and password access.

With support for SIP and ONVIF protocols, the JSL63 can be easily integrated with major IP PBX, NVR, and video management systems, offering excellent compatibility with third-party platforms. Designed for apartments, office buildings, gated communities, and industrial parks, it can be customized for various project needs—combining high performance, durability, and elegant design for smart building communication systems.

Send email to us

Product Detail

Product Tags

Product Fetures

• 5 quick call buttons with customlabel

• Equipped with a 2megapixel HDR high-definition camera, itprovides clearer imaging

• IP66 & lKO7 high protection rating, wide temperature operation,suitable for harsh outdoor environments

• Equipped with a wide range of interfaces for connecting varioussecurity devices

• Supports the standard ONVIF protocol，providing high flexibilityand excellent compatibility

Specification

Panel Type	Townhouse, Office, Small apartment
Screen/Keyboard	Quick call button×5, Customlabel
Body	Aluminum
Colors	Gunmetal
Sensor	1/2.9-inch，CMOS
Camera	2 Mpx,Support infrared
Viewing Angle	120°(Horizontal) 60°(Vertical)
Output Video	H.264 (Baseline, Main Profile)
Light Sensitivity	0.1Lux
Card Storage	10000
Power Consumption	PoE: 1.70~6.94W Adapter: 1.50~6.02W
Power Supply	DC12V / 1A POE 802.3af Class 3
Working Temperature	-40℃~+70℃
Storage Temperature	-40℃~+70℃
Size of the Panel (LWH)	177.4x88x36.15mm
IP / IK Level	IP66 / IK07
Installation	Wall-mounted Flush-mounted(Need to purchase accessories separately：EX102)

Functional Capabilities

SupportedProtocols	SIP 2.0 over UDP/TCP/TLS
Lock Opening	IC/ID Card, By DTMF Code, Remote door opening
Interface	Wiegand Input/Output Short Circuit Input/Output RS485 (Reserve) Line out for induction loop
Supported Wiegand	26, 34 bit
Supported ONVIF Types	Profile S
Supported Standards	Mifare Classic 1K/4K, Mifare DESFire, Mifare Ultralight, Mifare Plus Cards 13.56 MHz, Cards 125 kHz
Talking Mode	Full duplex (High-definition Audio)
Additionally	Built-in relay, Open API, Motion detection, Tamper alarm, TF Card
